Locks on Moselle: map, chamber sizes and draught
Moselle, Germany: 10 locks with published chamber figures. The smallest chamber is 170.00 m long and 12.00 m wide; the lowest maximum draught is 3.00 m (EuRIS Locks_v2, 2026-10-08).
| Lock | Chamber L x B | Max draught | Map |
|---|---|---|---|
| Detzem | 170.00 x 12.00 m | 3.00 m | Map |
| Enkirch | 170.00 x 12.00 m | 3.00 m | Map |
| Fankel | 170.00 x 12.00 m | 3.00 m | Map |
| Koblenz | 170.00 x 12.00 m | 3.00 m | Map |
| Lehmen | 170.00 x 12.00 m | 3.00 m | Map |
| Mueden | 170.00 x 12.00 m | 3.00 m | Map |
| St. Aldegund | 170.00 x 12.00 m | 3.00 m | Map |
| Trier | 170.00 x 12.00 m | 3.00 m | Map |
| Wintrich | 170.00 x 12.00 m | 3.00 m | Map |
| Zeltingen | 170.00 x 12.00 m | 3.00 m | Map |
Where a lock has no draught of its own, the table gives the waterway's published maximum draught at that point.
